| Cylinders |
Interchangeable lift and reeving cylinders 8 in. bore X 79 in. stroke single stage |
|
| Fenders |
Poly replaceable and interchangeable |
|
| Air Shift PTO |
With direct mounted pump |
|
| Hydraulic Tank |
40 gallon capacity, side mounted steel |
|
| Frame |
10 in. X 4 in. X 1/2 in rectangular tubing |
|
| Lights |
Enclosed sealed beam lights mounted in rubber |
|
| Controls |
Cable inside and outside of cab |
|
| Outside Rollers |
4 in. O.D. X 3 3/4 in. long with Aluminum Bronze Bushings |
|
| Sheaves |
10 in. Diameter with Aluminum Bronze Bushings for longer life |
|
| Rear Hinge |
Heavy-Duty Steel with 32 in. pin surface |
|
| Grease Fittings |
At all wear points |
|
| Lift Capacity |
50,000 to 60,000 lbs. |
|
| Dump Angle |
Approximately 50 degrees |
|
| Operating Pressure |
1900 PSI |
|
|
|
| Valve |
Multiple Stack - 4 Way Sections |
|
| Filter |
100 GPM in-tank return line |
|
|
|
| Rear Hold Down |
Ratchet Tie Downs |
|
| Wear Strips |
1/2 in. X 3 in. bar |
|
Tuff Kote Hoses
