| Capacity |
2 Thru 10 Cubic Yard Containers |
|
| Self Leveling Forks |
1 1/4 in. X 4 in. Bar, Front Loader Containers with Rotator 1 1/2 in. X 4 in. |
|
| Tilt Cylinders |
Two 4 in. Bore X 20 1/2 in. Stroke |
|
| Lift Cylinders |
Two: 4 in. Bore X 32 in. Stroke; Two: 4 in. Bore X 32 in. Stroke with Rotator |
|
| Fenders |
Rolled Fenders 1/8 in. Steel |
|
| Hydraulic Tank |
10 Gallon Capacity |
|
|
|
| Pivot Points |
Aluminum Bronze Bushings |
|
| Grease Fittings |
At All Wear Points |
|
|
|
| Pump Clutch |
Belt Driven 12 Volt |
|
|
|
|
|
| Operating Pressure |
1200 PSI |
|
| Chassis Specs |
1 Ton Minimum Capacity; 2 Tons Recommended Capacity; Cab-to-Axle 60 in. Minimum; After Frame 32 in. |
|
Complete Hydraulic Kit - Bi-Rotation Pum
