| Cylinders, Lift |
5" bore x 59" stroke single stage, double acting |
|
| Cylinders, Reeving |
5" bore x 80" stroke single stage, double acting |
|
| Fenders |
Poly Fenders Interchangeable and Replaceable |
|
| Air Shift PTO |
Direct Mount Pump when possible |
|
| Hydraulic Tank |
40 gallon capacity, side mount |
|
| Frame |
8" x 4" x 3/8" rectangular tubing |
|
| Rear Stops |
Ratchet Tie Downs |
|
| Front Stops |
1" thick steel |
|
|
|
| Controls |
Cable inside and outside of cab |
|
| Outside Rollers |
4" O.D. with bronze bushings |
|
| Sheaves |
10" diameter with aluminum bronze bushings |
|
| Grease Fittings |
At all wear points |
|
| Lift Capacity |
30,000 lbs. |
|
| Dump Angle |
Approximately 50 degrees |
|
| Operating Pressure |
1750 P.S.I. |
|
| Pump |
41 G.P.M. at 1500 R.P.M. |
|
|
|
| Filter |
71 G.P.M., 10 Micron |
|
| Front Container Latch |
Standard |
|
| Chassis Front GVWR |
12,000 lbs. recommended |
|
| Chassis Rear GVWR |
20,000 lbs. recommended |
|
| Total Chasis GVWR |
32,000 lbs. recommended |
|
| Chasis - Cab to Axle |
148" to 155 1/2" (18 feet) |
|
| Chasis - Frame Height |
38" to 43" |
|
Steel Tubing
